EG4 12000XP - Warning Definitions and Troubleshooting

67
E029
Sync trigger signal lost in parallel
system
Ensure the CAN cable connection is connected to the
correct COM port.
E031 Internal communication fault 4
Restart the inverter. If the error persists, contact the
distributor.
15.2 WARNING DEFINITIONS AND TROUBLESHOOTING
CODE DESCRIPTION TROUBLESHOOTING
W000 Communication failure with battery
Check the inverter battery settings to ensure they
are set for the specific battery type. Check the
battery communications cable for proper
pinning/installation.
W001 AFCI Com failure
Restart the inverter. If the error persists, contact the
distributor.
W002 AFCI High
Check each PV string for correct open circuit
voltage and short circuit current. If the PV strings
are in good condition, clear the fault on inverter
LCD.
W003 Meter communication failure
Check communications cable. If the error persists,
contact the distributor.
W004 Battery BMS fault
Inverter is receiving a fault from the battery’s BMS.
Restart the battery and ensure the communication
cables are installed correctly. If the error persists,
contact the distributor.
W006
RSD Active
Check if the RSD switch is pressed.
W007 LCD communication fault
Restart the inverter. If the error persists, contact the
distributor.
W008
Firmware mismatch
Contact the distributor for a firmware update.
W009
Fan Stuck
Verify the fans are operable.
W011 Stack overflow
Restart the inverter. If the error persists, contact the
distributor.
W013 Over temperature
The temperature of the inverter is nearing the high
limit.
W014
Multi-Master set in parallel system
There can be only one master in a parallel system.
W015 Bat Reverse
Double check battery connections to inverter are
properly installed. If the error persists, contact the
distributor.
W017
AC voltage out of range
Verify AC voltage is within operating range.
W018
AC Frequency out of range
Verify AC frequency is within operating range.
W019 AC inconsistent in parallel system
Ensure the AC input is from a common source and
installed to each inverter in parallel. Restart the
inverter. If the error persists, contact the distributor.
W020 PV Isolation low
Restart the inverter. If the error persists, contact the
distributor.
W022 DC injection high
Restart the inverter. If the error persists, contact the
distributor.
W025
Battery voltage high
Battery voltage is nearing the high limit.
W026
Battery voltage low
Battery voltage is nearing the low limit.
