(Page 2 / 3)
AC Chg Based On: According to time
AC charging is configured according to time using up to three
time periods. If one of the three time periods is met, AC will
charge the battery. If only one time period is needed, it is
recommended to set all time periods to the same value.
Range is 00:00 – 23:59.
AC Chg Based On: According to Bat Volt
AC charging based on according to battery voltage. The
starting charge voltage and ending charge voltage can be
configured. If the battery voltage is within the start voltage
and end voltage, AC will charge the battery. If using battery
communications, it is recommended to use SOC instead
of voltage (see next setting). Range is 38.4 – 57V for start and
48 – 59V for end.
AC Chg Based On: According to Bat SOC
AC charging configured according to battery SOC. Start
charge SOC and stop charge SOC can be set. If the battery
SOC is within the start and end SOC, AC will charge the
battery. Range is 1 – 90% for start and 20 – 100% for end.
