EG4 6000XP User Manual

48
5
Buzzer Enable
This setting allows the user
to enable or disable the
inverter buzzer.
Inverter Buzzer:
Enable/Disable
Default: Enable
6
Ic:
Maximum Charge
Current
(Utility+Solar)
This setting allows the user to
set the maximum charge
current.
Total Charge Current:
Range: 0 – 125A
Default: 125A
AC Charge Current:
Range: 0 – 125A
Default: 30A
Generator Charge Current:
Range: 0 – 110A
Default: 30A
7
ConChr:
CV Voltage (Lead-
Acid Only)
This setting allows the user to
set the Charging Voltage for
Lead-Acid batteries only.
Lead-Acid Charging Voltage:
Range: 50.0 – 59.0VDC
Default: 56.4VDC

EG4 6000XP Specifications

General

Nominal DC Voltage	48V
Maximum DC Voltage	500V
Maximum Continuous Output Power	6000W
Frequency	60Hz
Model	EG4-6000XP
Peak Power	12000W
Protection Features	Over Voltage, Over Load, Over Temperature, Short Circuit
Cooling	Fan
