Eldan Recycling A/S Page 4
1. START/STOP PROCEDURE
1.1 Start procedure
Check that all conveyors/transport routes are free from dangerous objects
such as tools, bolts, etc.
Switch on the main switch (H1). The system is now live.
The touch panel is switched on and the Start screen appears.
Switch on the control current key (B351).
Now press Start/Reset on the control panel and the white control current lamp
with light up.
The system can now be started using the procedure described on the next
page.
Load %
Motor 1
0 %
Rasper
ON
Outlet
ON
Inlet
ON
Rasper
OFF
Outlet
OFF
Inlet
ON
Curve Language
Alarm
List
Alarm
History
Adjustment
Load %
Motor 2
0 %
Rotor Speed
0
Temperatur
Fahrenheit MPR200
Temperatur
Fahrenheit Outlet
0 0
Time
To Next Page
