Electrolux E36DF76EPS User Manual

80
FAILURE
Electrical components will not
operate.
Flame too large and yellow on
top burner.
Flame too small on top
burner.
Flame goes out, when valve
is turned to the low position.
Top burners, not burning
properly.
CORRECTION
1. Check fuse or circuit breaker.
2. If good check line to neutral and
line to line voltage, at the range
terminal block.
1. Has the range being installed on
LP gas without being converted?
2. Check gas pressure at the top
burners under flow. The pres
sure reading should be 10
inches of water column pressure
for LP gas and 4 inches of water
column pressure for natural. Is
the pressure reading correct?
1. Check gas pressure at the top
burners under flow. The
pressure reading should be 10
inches of water column pressure
for LP gas and 4 inches of water
column pressure for natural. Is
the pressure correct?
1. Has the bypass orifice been
adjusted?
1. Are the burner rings and caps
installed correctly?
2. Check gas pressure at the top
burners under flow. The
pressure reading should be 10
inches of water column pressure
for LP gas and 4 inches of water
column pressure for natural. Is
the pressure correct?
If defective replace the fuse or reset the
circuit breaker. If good go to step 2
If the voltage readings are correct, there’s
a wiring problem in the range, check the
range wiring.
If the voltage readings are incorrect, de-
fective house wiring or defective range
cable.
Yes, install LP conversion kit.
No,
Yes, check for something blocking the air
inlet to the burners.
No, check gas supply pressure, the pres-
sure regulator or for a restriction in the
gas line.
Yes, incorrect orifice size or restricted ori-
fice.
No, the range is installed on LP and pres-
sure regulator is set for natural. Defec-
tive regulator or low incoming gas pres-
sure.
Yes, clean or replace the bypass orifice.
No, adjust the bypass orifice
Yes, go to step 2.
No, install burner rings and caps correctly.
Yes, adjust air shutters.
No, checked gas supply pressure, the
pressure regulator or for a restriction in
the gas line.
CHECK
