83
FAILURE
Oven temperature off more
than 10°
Oven does not operate in
bake.
CHECK
1. Remove power from the range.
Disconnect plug P5 from
electronic oven control board
and measure the resistance
between pins eight and nine
(oven sensor circuit) in the
harness. Is the reading,
between 1050 and 1100 ohms?
2. Set the temperature selector to
300°, disconnect plug P 9 from
the electronic oven control board
and measure the resistance
between pins one and three in the
harness. Multiply the resistance
reading by 32.7%. Measure the
resistance between pins two and
three. Is this reading within 5% of
the first reading?
1. Does the oven heat in any other
function?
2. Disconnect power from the
range, remove the two screws
holding the bake element to the
rear wall of the oven and pull
element into the oven.
Disconnect one wire from the
element and check the
resistance of the element it with
an ohm meter. Large ovens the
resistance should be 17 ohms
+/-10%, small ovens the
resistance should be 27 ohms
+/ -10%. Is the reading correct?
CORRECTION
Yes, go to step 2.
No,
go to the back of the range and check
the oven sensor.
Yes, replaced the electronic oven control
board.
No, replace the temperature selector.
Yes, go to step 2.
No, refer to oven does not operate.
Yes, defective electronic oven control
board.
No, replace the bake element.
