90
Removing the knob bezels:
1. Remove the knob.
2. Remove the two screws holding the bezel to the
control panel.
Removing the backsplash:
1. Remove the grates.
2. Remove the (4) screws, two on each side, from the
rear of the range holding the backsplash to the side
panels.
3. Remove the (4) screws holding the front of the
backsplash to the burner box and lift the backsplash
off.
Removing the spill tray:
1. Remove the grates and burner heads.
2. Removed the (3) screws holding the control panel
to the front spill tray support.
3. Lift the front of the spill tray up, to clear the control
panel, and lift the spill tray out.
