9
Max lock Time Set the oven up for a clean cycle. Does the latch motor turn?
exceeded (motor No. Check the voltage applied to the latch motor. If line to neutral,
door latch) replace latch mechanism. If zero, replace electronic control board.
Yes. Check the phase and lock switches. They should be closed with
the door locked and open with a door unlocked. If the switches check
good replace the electronic control board.
Max lock Set the oven up for a clean cycle. Does the latch motor turn?
Attempts exceeded No. Check the voltage applied to the latch motor. If line to neutral replace
(motor door latch) latch mechanism. If zero replace electronic control board.
Yes. Check the phase and lock switches. They should be closed with the
door locked and open with a door unlocked. If the switch check good replace
the electronic control board.
Inter processor Replace electronic control Board.
communications
failure (motor
door latch)
Resistance chart
Oven sensor 1050 to 1100 ohms
Bake element (large oven) 17 ohms +/-10%
Bake element (small oven) 27 ohms +/-10%
Broil element (large oven) 14 ohms +/-10%
Broil element (small oven) 19 ohms +/-10%
Convection element (large oven) 26 ohms +/-10%
Convection element (small oven) 26 ohms +/-10%
Convection fan motor 58 ohms +/-10%
Cooling fan motor 10 ohms +/-10%
Oven light transformer primary 62 ohms +/-10%
Oven light transformer secondary 1 ohms
locked motor 2500 ohms +/-10%
