87
FAILURE
Oven does not operate in self-
cleaning.
One oven light does not light.
Both oven lights do not light.
CHECK
1. Are the front panel LEDs
indicating a service failure mode?
2. Have the oven racks and side glides
been removed?
3. Does the oven heat in the baked
function?
4. Does the oven door lock?
5. Disconnect power from the range.
Remove plug P5 and measure the
resistance between pins five & ten in
the harness. Does the meter read zero
or infinity?
6. Measure the resistance between pins
one and two in the harness of plug
P5. Does the meter read 2500 ohms
+ /-10%?
1. Check the oven light bulb.
1. Check the oven light bulbs.
2. Check the light switch.
CORRECTION
Yes, checked service failure mode
chart.
No, go to step 2
Yes, go to 3.
No, remove the racks and side
glides.
Yes, go to 4.
No, refer to oven will not operate in
bake function.
Yes, defective electronic oven con-
trol board.
No, go to step 5.
Zero, go to step 6.
Infinity, defective rack removal
switch or wiring to the switch.
Yes, replace electronic oven control
board.
No, defective lock motor or wiring
between the electronic oven control
board and the lock motor.
Good bulb, defective transformer or
wiring between the transformer and
the socket.
Defective bulb, replace the bulb.
Good bulbs, go to step 2.
Defective bulbs, replace the bulbs.
Good switch, defective transformer
or wiring.
Defective switch, replaces the
switch.
