3 Local Operation of the Flatpack MCU
Operation Guide Flatpack MCU,
351300.013, v8-2006-07
13
3.2.2 Menu Options
This chapter gives a short description of the menu options that can be accessed from the front keypad. The
description includes an overview of the keys to press to select the actual option.
3.3 User Options and Service Options
By dividing the available menu options into two levels — User Options and Service Options — it is easier to
operate the system. Special not so frequently used options—such as calibration and adjustments — are
included in the Service Options sub-menus.
While the User Options menus are available to all users, the Service Options sub-menus are password-
protected and only authorised personnel have access to them.
For Hierarchy of Menus, see page 12
9
The Service Options password is factory-programmed to «0000» and «0003». We
strongly recommend that you change the passwords right after system installation
3.3.1 Available User Options
The following User Options menus are available to all users via the Flatpack MCU front keypad:
• Switch the system ON / OFF (May be disabled)
• Reset alarms
• Display important system voltages
• Display alarm messages
• Display the system’s software and version numbers
3.3.2 System ON / OFF (System On/Off)
In order to switch the system ON — or OFF— see Hierarchy of Menus, page 12.
3.3.3 Resetting Alarms (Alarm Reset)
All alarms in the system are — as default— automatically reset, when the cause of the alarm is removed. Nevertheless,
Flatpack MCU enables you to reset all active alarms that are configured as manually resettable alarms. Alarms still
active after resetting will be reported again; refer to chapter 4.9.2 Alarm Setup/Display.
For Hierarchy of Menus, see page 12
9
NOTE: In MPSU systems or in systems without batteries, the ON/OFF
function may have been disabled
