3 Local Operation of the Flatpack MCU
Operation Guide Flatpack MCU,
351300.013, v8-2006-07
15
3.3.8 Adjustment of Important System Voltages (VoltAdsjustment)
The menu option VoltAdjustment, in Service Options, enables adjustment of the following system voltages:
NomVolt
Nominal output voltage
BoostVolt
Battery boost-charging voltage
LowBatt 1
Voltage limit for Low Battery Alarm 1
LowBatt 2
Voltage limit for Low Battery Alarm 2
HighBatt 1
Voltage limit for High Battery Alarm 1
HighBatt 2
Voltage limit for High Battery Alarm 2
LVD 1
Voltage limit for disconnect unit 1
LVD 2
Voltage limit for disconnect unit 2
LVD 3
Voltage limit for disconnect unit 3
For Hierarchy of Menus, see page 12
3.3.9 Output Voltage Calibration (Calibration)
This menu option, in the Service Options menus, enables calibration of the output voltage.
To calibrate the output voltage, browse to the Calibration Menu, measure the bus voltage for the system (refer
to the Installation Guide), and key in the calibration value.
To reset calibration values to default, browse to the Calibration Menu, and enter the option SetDefaultCalib.
For Hierarchy of Menus, see page 12
3.3.10 Change of Service Options Password (ChangePassword)
The access password to Service Options menus may be changed by using this menu option.
9
The Service Options password is factory programmed to «0000» and «0003». We
strongly advise that this password is changed as soon as the system is installed.
The password must be a four digit format from «0000» to «9999» - otherwise access will be denied.
To For Hierarchy of Menus, see page 12
3.3.11 Changing Boost-Charging Duration (SetBoostTime)
This menu option, in the Service Options menus, enables adjustment of the boost charging time of the
batteries.
For Hierarchy of Menus, see page 12
3.3.12 Start or Stop Boost Charging (Start/StopBoost)
This menu option, in the Service Options menus, enables manual start or stop boost charging of batteries.
