Chapter 2 Product Introduction 9
 Note
Any special requirements for braking, please contact your supplier or Emerson
Network Power.
2.5.4 Operation Keypad Pedestal and Cables
The operation keypad pedestal and connecting cables are optional.
Small end
Figure 2-4 Operation keypad base
Figure 2-5 Operation keypad cable
Figure2-4 shows TDF-KB01 operation keypad pedestal.
There are three kinds of cables for operation keypad: TDC-CB0006A (0.6m),
TDC-CB0015A (1.5m), TDC-CB0030A (3.0m). See Figure 2-5.
