Emerson Network Power TD3200 Series User Manual

Chapter 5 Parameters Table 31
Para. Name Range Min.unit Default Mod.
F004
Operating direction
selection
0: Conformed to the
pre-set direction
1: Reversed to the
pre-set direction
1 0
×
F005
Low-speed operation
setting
0.00~50.00Hz 0.01Hz 3.00Hz
×
F006 Limit of CD or OD time 0.1~3600s 0.1s 300.0s
×
F007
Delay time for OD
terminal command
0~3600.0s 0.1s 0.0s
×
F008
Delay time for CD
terminal command
0~3600.0s 0.1s 0.0s
×
5.2 OD/CD Operating Parameters
Para. Name Range Min.unit Default Mod.
F009
Display selection for
F009~F025
0: Not display
1: Display
1 0
○
F010 OD start torque
0.0%~150%(motor
rated torque)
0.1% 50.0%
×
F011 OD startup Acc time 0.1~3600s 0.1s 1.0s
○
F012
Low speed setting in
OD startup process
0.00~50.00Hz 0.01Hz 10.0Hz
×
F013
Low speed maintaining
time at OD start
0.1~3600s 0.1s 1.0s
○
F014
OD reference
frequency setting
0~Max. frequency(Hz) 0.01Hz 35.00Hz
○
F015 OD Acc time 0.1~3600s 0.1s 2.0s
○
F016
Initial time of "S" shape
curve in OD Acc
process
10.0%~50.0%( Acc/Dec
time)
F016+F017
≤
90%
0.1% 20.0%
×
F017
Rising time of "S"
shape curve in OD Acc
process
10.0%~80.0%( Acc/Dec
time)
F016+F017
≤
90%
0.1% 60.0%
×
F018 OD Dec time 0.1~3600s 0.1s 2.0s
○
TD3200 Variable Speed Drive for Elevator Door Control User Manual
