Chapter 4 Operation 23
Note
You cannot do any operation on the status display unit.
4.1.2 Drive's Operating Status Descriptions
A drive has 4 operating status.
Stopping status-The drive is switched on but without any operation.
Programming state-Use operation keypad to modify and set function
parameters
Operating status-The drive's U, V, W terminals have electricity outputs
Fault alarming status-When fault occurs either from external equipment,
internal or wrong operation, the drive's LED will display the fault code and
lock output
4.1.3 Operating Mode Descriptions
The drive has 4 operating modes: Speed control 1, Speed control 2
(multi-speed control application), Distance control 1, Distance control 2.
4.1.4 Parameter Classification
There are 124 parameters totally, which are divided into 12 groups according
to their functions:
1. F000-F008: for basic operation function parameters' setting
2. F010-F024: for OD curve parameters
3. F027-F042: for CD curve parameters
4. F044-F054: for distance control parameters
5. F055-F062: for MS control
6. F063-F066: only for demo of operation
7. F068-F081: for motor's parameters
8. F082~F084: auxiliary parameter
9. F088~F095: vector control parameter
10. F097~F106: digital I/O parameter
TD3200 Variable Speed Drive for Elevator Door Control User Manual
