Chapter 5 Parameters Table 39
5.10 Display and Monitoring Parameters
Para. Name Range
Min.
unit
Default Mod.
F109
Display selection
F109 ~F122
0: Not display
1: Display
1 0
○
F110
Parameters displayed
by LED during
operation
Setting of the bit:
0: not display
1: display
BIT0: operating frequency
(Hz)
BIT1: reference frequency
(Hz)
BIT2: output voltage
(V-RMS)
BIT3: output current
(A-RMS)
BIT4: output torque (%)
BIT5: DC bus voltage
(V-AVE)
BIT6: status of idgital input
terminal(no unit)
BIT7: status of idgital
output terminal(no unit)
BIT8: low bit of pulse
number of door
location(0~9999)
BIT9: high bit of pulse
number of door
location(0~9999)
Note: all the values F110
chooses to monitor can be
displayed by pressing
XX
key during operating,
1
31(00011111B
)
○
