Chapter 3 Installation and Wiring 13
Table of Control Terminals Functions
Terminal
Terminal
Code
Terminal function
description
Specification
Multi-function
input terminal
X1
～
X7
Functions are
programmable (reference
GND is COM)
OD
OD command (reference
GND is COM)
Terminals for
inputting OD
and CD
commands
CD
CD command (reference
GND is COM)
24V input, X1 and X2
can meet the input
requirements of pulse
signal with frequency
below 40kHz
P24
24V power supply
(reference GND is COM)
+24V, maximum output
current is 100mA
PA, PB, PC
Programmable relay
output 0
PAC, PC1
Programmable relay
output 1
Output
terminals
PAC, PC2
Programmable relay
output 2
Ratings of contacts:
AC: 250V/2A;
DC: 30V/1A
3.3.3 Wiring of Drive
The basic wiring of drive's input/output terminals and external equipment are
illustrated in Figure 3-5.
The control terminals in the Figure below are used for setting frequency,
operation control and outputting the drive's status to external monitoring
devices. Its wiring method depends on your application.
TD3200 Variable Speed Drive for Elevator Door Control User Manual
