Emerson Network Power TD3200 Series User Manual

12 Chapter 3 Installation and Wiring
When TD3200 is used for controlling elevator 's door, it should be installed on
the top of the elevator car (external surface). It's recommended to be installed
vertically or placed obliquely, at 45°with the horizontal surface, with
protective covering.
3.3 Wiring
 Note
Refer to Chapter 7 Application Guidance if the drive is used for controlling the
elevator door, in which the wiring methods, testing and parameter settings of several
typical elevator door control applications are given.
3.3.1 Power Terminals of Main Circuit
P(+) (—)
PB
L N
U WV
 Note
Safety earthing cable should be connected to the screw marked with " "
Functions of Power Terminals
Terminal Name Function
P(
＋
), PB, (
―
)
P(
＋
): "+" bus;
PB: terminal for connecting braking unit, (
—
): "-" bus;
L. N Input terminals for single-phase 220Vac
U. V. W Output terminals for motor
PE Terminal for earthing
3.3.2 Control Terminals
PA PB PC PAC PC1 PC2
P24 COM X1 X2 X3 X4 X5
X6
X7
COM
OD
CD
TD3200 Variable Speed Drive for Elevator Door Control User Manual
