Emerson Network Power TD3200 Series User Manual

Chapter 6 Parameter Descriptions 69
6.9 Digital I/O
F096 Display selection for F096~F108
Range: 0, 1
【
0
】
F096 decides whether to display F097~F0108.
0: Not display
1: Display
Function and parameters of control terminal X1~X7 are defined by the
following parameters.
F097 Function selection for control terminal X1
Range: 0~23
【
0
】
F098 Function selection for control terminal X2
Range: 0~23
【
0
】
F099 Function selection for control terminal X3
Range: 0~23
【
0
】
F100 Function selection for control terminal X4
Range: 0~23
【
0
】
F101 Function selection for control terminal X5
Range: 0~23
【
0
】
F102 Function selection for control terminal X6
Range: 0~23
【
0
】
F103 Function selection for control terminal X7
Range: 0~24
【
0
】
Control terminals X1~X7 are programmable input terminals, and their
functions can be defined by F097~F103. The functions are listed in Table 6-2.
Table 6-2 Function selection for multi-function inputs
Settings Functions Settings Functions
0 No functions 12
Normally open input contacts for
OD speed changing
1
External reset (RESET)
signal input
13
Normally closed input contacts
for OD speed changing
2
Normally open input
contacts for optical signal
14
Normally open input contacts for
CD speed changing
3
Normally closed input
contacts for optical signal
15
Normally closed input contacts
for CD speed changing
4
Normally open input
contacts for touching board
16 MS speed terminal 1
5
Normally closed input
contacts for touching board
17 MS speed terminal 2
6
Normally open input for OD
location limiting
18 MS speed terminal 3
TD3200 Variable Speed Drive for Elevator Door Control User Manual
