20 Chapter 3 Installation and Wiring
3.4.3 Installation of Braking Resistors
Connect braking resistor between "P (+)" and "PB" with cables of proper
diameters, as shown in Figure 3-12.
M
L
N
U
V
W
PE
PB
P(+)
Braking resistor
● ●
● ●
Figure 3-12 Connection between braking resistor and drive
TD3200 Variable Speed Drive for Elevator Door Control User Manual
