36 Chapter 5 Parameters Table
Para. Name Range Min.unit Default Mod.
F079 Rotator inductance 0~9999mH 1mH 357mH
×
F080 Mutual inductance 0~9999mH 1mH 325mH
×
F081
Magnetising current
without load
0.00~99.99A 0.01A 1.08A
×
5.7 Auxiliary Parameters
Para. Name Range Min.unit Default Mod.
F082 Carrier frequency 2.0kHz~16.0kHz 0.1kHz 8.0kHz
×
F083
Auto reset times upon
fault
0~100, 0 means
without auto reset
function (reset interval
time :2s)
1 0
×
F084 Utility rate of braking
0: Without dynamic
braking 1:
2.0%
2: 5.0%
3: 10.0%
4: 20.0%
5: 50.0%
6: 80.0%
7: 100.0%
1 7
○
F085 Reserved
F086 Reserved
5.8 Vector Control Parameters
Para. Name Range Min.unit Default Mod.
F087
Display selection F087
~F095
0: Not display
1: Display
1 0
○
F088 ASR proportional gain 1 0.000~6.000 0.001 1.000
×
F089 ASR integral time 1
0 (no action),
0.032~32.00s
0.001s 1.000s
×
F090 ASR proportional gain 2 0.000~6.000 0.001 1.200
×
TD3200 Variable Speed Drive for Elevator Door Control User Manual
