Emerson Network Power TD3200 Series User Manual

Chapter 5 Parameters Table 33
Para. Name Range Min.unit Default Mod.
F036
Initial time of "S" curve
in CD Dec process
10.0%~50.0%(Acc/Dec
time)
F036+F037
≤
90%
0.1% 20.0%
×
F037
Falling time of "S" curve
in CD Dec process
10.0%~80.0%(Acc/Dec
time)
F036+F037
≤
90%
0.1% 60.0%
×
F038
Low speed setting in
CD ending phase
0.00~50.00Hz 0.01Hz 2.00Hz
×
F039
Holding torque in
complete CD status
0.0%~150%(Motor
rated torque)
0.1% 50.0%
×
F040
Hindering torque setting
for CD high speed
phase
0.0%~150%(Motor
rated torque)
0.1% 100.0%
×
F041
Threshold setting for
CD torque changing
0.0%~150%(Motor
rated torque)
0.1% 50.0%
×
F042
Hindering torque
setting for CD low
speed end phase
0.0%~150%(Motor
rated torque)
0.1% 100.0%
×
5.3 Distance Control Parameters
Para. Name Setting Range Min.unit Default Mod.
F043
Display selection for
F043~F066
0: Not display
1: Display
1 0
○
F044
Number of pulse per
revolution
1~9999 1 128
×
F045
Number of phases of
PG
0: double phase
1: single phase
1 0
×
F046 Direction of PG
0: FWD
1: REV
1 0
×
F047
Speed in door-width
auto-learning
0~50.00Hz 0.01Hz 5.00Hz
×
