88 Chapter 7 Application Guidance
Functions Name Setting Remark
F082 Carrier frequency adjustment 8K
Set according to system
requirements
F084 Utility rate of braking 7
Set properly according to braking
condition
Attention
Setting of F006 must be bigger than the sum of time in all phases of CD or OD curve.
7.3 Distance control 2
In distance control 2, refer to Figure 7-2 for system configuration, and the PG
need not be connected to the shaft of the motor.
In distance control 2, except F001 set "3" (distance control 2), other
parameters are the same with those of distance control 1. Refer to 7.2.2 for
the testing procedures.
