Emerson Network Power TD3200 Series User Manual

34 Chapter 5 Parameters Table
Para. Name Setting Range Min.unit Default Mod.
F048
Door-width
auto-learning setting
0, 1. From 0
→
1 to
start door-width
auto-learning, then auto
turn to 0 after finishing.
Auto-learning is
effective in motor
manual tuning mode
1 0
×
F049
OD speed changing
position under Distance
control
60.0%~90.0%(door-widt
h )
0.1% 70.0%
×
F050
CD speed changing
position under Distance
control
60.0%~90.0%(door-widt
h)
0.1% 70.0%
×
F051
Pulse setting for
completely OD under
Distance control
80.0%~99.0%(door-widt
h)
0.1% 95.0%
×
F052
Pulse setting for
completely CD under
Distance control
80.0%~99.0%(door-widt
h)
0.1% 95.0%
×
F053
Lower four digits of
door-width pulse
0~9999 1 0
×
F054
Higher four digits of
door-width pulse
0~9999(*10000) 1 0
×
5.4 MS Speed Parameters
Para. Name Range Min.unit Default Mod.
F055 MS frequency 0 0.00Hz~Max. frequency(Hz) 0.01Hz 50.00
○
F056 MS frequency 1 0.00Hz~Max. frequency(Hz) 0.01Hz 5.00
○
F057 MS frequency 2 0.00Hz~Max. frequency(Hz) 0.01Hz 10.00
○
F058 MS frequency 3 0.00Hz~Max. frequency(Hz) 0.01Hz 15.00
○
F059 MS frequency 4 0.00Hz~Max. frequency(Hz) 0.01Hz 20.00
○
F060 MS frequency 5 0.00Hz~Max. frequency(Hz) 0.01Hz 30.00
○
F061 MS frequency 6 0.00Hz~Max. frequency(Hz) 0.01Hz 40.00
○
F062 MS frequency 7 0.00Hz~Max. frequency(Hz) 0.01Hz 50.00
○
