26 Chapter 4 Operation
Before tuning, motor must be free of load; otherwise, the results will be
inaccurate.
1. Press PRG key to enter programming state.
2. Set main parameters (Other parameters can use the defaults)
F069 ~ F073: Correctly input motor nameplate parameters (Please refer to
Chapter 5, 6 for detailed explanation of parameters)
F075=1: Tuning allowed
3. Press PRG key to return
4. Press RUN key to start motor parameter tuning and the LED displays
"
". In the tuning state, the motor runs on a fixed mode, so you need not
interfere. After the tuning is over, the drive stops automatically, F075 will
resume to "0" and the settings of F076~F081 will be updated. If the tuning is
obviously abnormal, press STOP key to stop it. Check the connections and
motor ratings, then set F075=1 again. Press RUN key to start tuning.
5. A successful tuning can ensure correct control of the motor.
Note
If you have known the motor's parameters, you can input them into F076~F081
directly, no need to start the tuning.
4.2.2 Basic Operating Modes
1. Operating frequency settings, tuning and operating control can be done via
operation keypad.
1) Press PRG key to enter programming state
2) Set main parameters (other parameters can use the defaults)
F055=5.00, MS frequency 0
F001=0, speed control 1 (sensorless vector control)
F002=0, in general keypad control mode
3) Press PRG key to return
4) Press RUN key and ▲ key together for FWD running. Press RUN key
and ▼ key together for REV running
TD3200 Variable Speed Drive for Elevator Door Control User Manual
