80 Chapter 7 Application Guidance
7.1.2 Testing Procedures
1) Wiring according to Figure 7-1;
2) Switch on the drive, set F123 to "2", resume the factory settings. Refer to
section 4.1 for parameter setting;
3) Make sure F002 is set to 0 (keypad control for general-purpose drive),
remove the load, and input the values on motor's nameplate to F069~F073
(refer to relevant parts in Chapter 5 & 6) Set F075 to "1", press RUN to start
tuning for getting motor parameters until the tuning process is over. In the
tuning process, the keypad will display "
". The parameters will
be saved automatically after tuning.
Note
Motor load should be removed during tuning, otherwise the motor parameters
obtained will be inaccurate or the tuning unsuccessful.
For the motor of same model and made by same manufacturer, just input the motor
parameters with reference to the previous motor parameters to set F076~F081,
unnecessary to start auto-tuning.
4) Set F002 to "2" (manual testing mode), set the parameters according to
table 7-1, press RUN and ▲ (or ▼) to start the operation. If bumping or
unsmooth operation occurs in the process, adjust the CD or OD curves
according to the OD curve for speed control 1 shown in Figure 6-5 and CD
curve for speed control 1 shown in Figure 6-6.
Attention
If the actual operation is reverse to OD/CD command, please change the setting of
F004 or change the phase connection of motor.
5) After testing, set F002 to "1" (terminal control mode), and the drive will
begin to work normally.
7.1.3 Parameters Setting
Please refer to Figure 7-1.
TD3200 Variable Speed Drive for Elevator Door Control User Manual
