Chapter 7 Application Guidance 81
Table 7-1 Parameter settings for Speed control
Functions Name Setting Remark
F001 Control mode 0 Speed control
F097
Function of digital input
terminal X1
12
Normally open input for OD speed
changing
F098
Function of digital input
terminal X2
14
Normally open input for CD speed
changing
F099
Function of digital input
terminal X3
6
Normally open input for OD location
limiting
F100
Function of digital input
terminal X4
8
Normally open input for CD location
limiting
F101
Function of digital input
terminal X5
2
Normally open input contacts for optic
signal
F102
Function of digital input
terminal X6
4
Normally open input contacts for
touching board
F103
Function of digital input
terminal X7
1 External reset (RESET) signal input
F105
Programmable relay
PAC/PC1
2 Output type 1 signal for complete OD
F106
Programmable relay
PAC/PC2
3 Output type 1 signal for complete CD
F010 Start torque for OD 50.0%
F011 OD startup Acc time 1.0s
F012
Low speed in OD startup
process
10Hz
F013
Low-speed maintaining
time at OD startup
1.0s
F014
OD reference frequency
setting
35Hz
F015 OD Acc time 2.0s
F016
Initial time of S curve in
OD Acc process
20.0%
F017
Rising time of S curve in
OD Acc process
60.0%
F018 OD Dec time 2.0s
F019
Initial time of S curve in
OD Dec process
20.0%
Parameters in the table are factory
settings, adjust the OD parameters
according to the actual OD operating
conditions.
TD3200 Variable Speed Drive for Elevator Door Control User Manual
