Emerson Network Power TD3200 Series User Manual

82 Chapter 7 Application Guidance
Functions Name Setting Remark
F020
Falling time of S curve in
OD Dec process
60.0%
F021
Low speed setting in OD
ending phase
3Hz
F022
Holding torque in
complete OD status
50.0%
F023
Threshold setting for
torque holding
50.0%
F024 Abnormal Dec time 0.5s
F027 Start torque for CD 50.0%
F028 CD startup Acc time 1.0s
F029
Low speed in CD startup
process
8Hz
F030
Low-speed maintaining
time at CD startup
1.0s
F031
CD reference frequency
setting
30Hz
F032 CD Acc time 2.0s
F033
Initial time of S curve in
CD Acc process
20.0%
F034
Rising time of S curve in
CD Acc process
60.0%
F035 CD Dec time 2.0s
F036
Initial time of S curve in
CD Dec process
20.0%
F037
Dropping time of S curve
in CD Dec process
60.0%
F038
Low speed setting in CD
ending phase
2Hz
F039
Holding torque for
complete CD
50.0%
F040 Hindering torque for CD
100.0
%
F041
Threshold of CD torque
changing
50.0%
Parameters in the table are factory
settings, adjust the CD parameters
according to the actual CD operating
conditions.
