Chapter 6 Parameter Descriptions 43
Chapter 6 Parameter Descriptions
Note
Reference frequency: Target frequency at which the drive operates stably.
Operating frequency: The drive's actual output frequency during operation.
The parameters in "【】" are defaults.
Only qualified personnel is allowed to test this product, otherwise,
accidents might occur;
Make sure that the mechanical system and electrical connections
of elevator door are correct, accidents might occur;
All the parameters must be set properly according to relevant
industrial standards, otherwise, accidents might occur;
Danger
!
Don't walk to the area where the door is under testing, otherwise,
personal injuries might occur.
6.1 Basic Operation Parameters
F000 User Password
Range: 0~9999
【
0
】
Set up any non- zero number as user's password to enable the password
protection function.
0000: no password, the access of parameter is not protected.
Attention
Once user's password is set, you can only read the parameters but not set or modify
them if you don't input the correct password.
F001 Control mode
Range: 0~3
【
0
】
0: Speed control 1
The drive operates in sensorless vector control mode. When the drive is used
to control an elevator door, the speed can be changed by connecting different
speed contacts, and the complete CD or OD can is controlled by a limit
switch.
1: Speed control 2
TD3200 Variable Speed Drive for Elevator Door Control User Manual
