Chapter 2 Product Introduction 5
2.3 Main Models of TD3200 Series Drive
Drive's model
constant-torque Load
Rated input
current (A)
Rated capacity
(kVA)
Rated output
current (A)
Motor
power (kW)
TD3200-2S0002D 2.65 0.5 1.3 0.2
TD3200-2S0004D 5.3 1.0 2.5 0.4
2.4 Product Specifications
Items Subitems Specifications
Voltage range Single-phase: 180V~264V
Input
Frequency range
50Hz
±
5%, 60Hz
±
5%
Voltage range Three-phase: 0~220V
Frequency range
0Hz
～
400Hz
Output
Over load ability
150% rated current for 1 minute, 180% rated
current for 10 seconds;
Modulation mode Optimized space voltage vector PWM modulation
Control algorithm
Sensorless vector control, vector control with
speed sensor
Operation mode
Two modes: 1: The drive operates as a drive
specially used for controlling the elevator door
(elevator door control mode); 2: The drive
operates as a general purpose drive
Frequency resolution Digital setting: 0.01Hz
Auto learning
The drive operates at the auto-learnt speed, and
operates in the logic procedure of close door (CD)
→
open door (OD)
→
CD
→
stop. After the
auto-learning operation, the door width
information is saved and the auto learning
process is over.
Main
control
functions
Auto tuning of motor's
parameters
Purpose of auto tuning function of drive is to
obtain the motor's parameters automatically and
these parameters will be saved automatically
after the tuning process is over.
TD3200 Variable Speed Drive for Elevator Door Control User Manual
