6 Chapter 2 Product Introduction
Items Subitems Specifications
Auto operation testing
upon start
In elevator door control mode, once the drive is
switched on, the door will be closed automatically,
after the door is closed completely, the drive will
stop and the door stays in completely-closed
status.
Main
control
functions
Acc/Dec curve
Acc/Dec according to S curve, the Acc/Dec speed
is selectable
Brake
Built-in braking unit, braking resistor connected
externally, utility rate of braking: 0 ~100%
Carrier frequency 2~16kHz
Multi-speed running
External terminals can be selected 8-level speed
running
Speed-adjusting range
Under rated load condition, 1:100 for vector
control with speed sensor; 1:50 for sensorless
vector control
Speed accuracy
Under rated conditions, with speed sensor: 0.5%
rated speed
Sensorless: 1% rated speed
Main
control
functions
Start torque
150% rated torque for control mode with speed
sensor at 15~300 rpm (for 4-pole motor)
150% rated torque for sensorless control mode at
30~300 rpm (for 4-pole motor)
Control mode Terminal control mode; keypad control mode
Frequency setting
Set the frequency via keypad; operate at
multi-speed level
Input signal
OD/CD command signal, CD/OD speed changing
control signal, OD/CD location limiting signal,
external reset signal; optical protection signal, MS
speed control signal, OD prohibition protection
signal, torque maintaining prohibition signal, low
speed control signal, PG signal, door lock signal
Operation
Functions
Display
Output signal
3 relay-output: 250VAC/2A(cos
φ
=1),
250VAC/1A(cos
φ
=0.4), 30VDC/1A
TD3200 Variable Speed Drive for Elevator Door Control User Manual
