Chapter 2 Product Introduction 7
Items Subitems Specifications
4-digit LED display
(select TDP-LED02)
Running frequency, reference frequency, output
frequency, output voltage, bus voltage, output
current, output torque, DC bus voltage, status of
digital input terminals, status of digital output
terminals, door-operating location (pulse number)
Protection function
Over current protection, over voltage protection,
low voltage protection, over heat protection,
overload protection, alarm for motor's parameters
tuning, alarm for parameters setting error, OD
width auto-learning error, OD/CD error, output
phase failure protection, alarm for CPU error,
parameter r/w error, and current detection circuit
fault
Optional parts
Operation keypad, status display unit, braking
resistors; cables of operation keypad, operation
keypad base, cables for operation keypad
Application
environment
Inside, free from direct sunlight, dust, corrosive
gas, combustible gas, oil mist, steam, water drop,
etc.
Elevation
Lower than 1000m (deration required for
elevation above 1000m)
Working
temperature
－
10
℃～＋
50
℃
Humidity Less than 90%RH, no condensation
Vibration Lower than 5.9m/s
2
(0.6g)
Environment
Storage
temperature
－
40
℃～＋
70
℃
Protection
IP20 (under conditions of using TDP-LED02 or
TDP-LED03) Structure
Cooling Natural air cooling without fan
Mount modes Mounted on the wall or inside cabinet
TD3200 Variable Speed Drive for Elevator Door Control User Manual
