24 Chapter 4 Operation
11. F110~F121: display and monitoring
12. F124: for factory use, not open to users.
Note
Function parameters in group 2~4, 7 and 9~11 are set by the manufacturer as NOT
DISPLAY (parameters packed). If you want to display some of the above parameters,
please set F009 (group 2), F026 (group 3), F043 (group 4), F067 (group 7), F087
(group 9), F096 (group 10) or F109 (group 11) to "1". Please refer to Chapter 5 and
Chapter 6 for details.
4.1.5 Parameter Setting Method
Parameters can be set via the keypad only.
Look at the example below: modifying F005 (low-speed operating speed)
from 3Hz to 4Hz.
1. Press PRG key - to enter programming state
The LED on the keypad will display current parameter code (e.g. F000)
2. Press ▲, ▼ key or SHIFT key - to search the parameter to be modified
(F005)
Note
If there is no continuous display of parameters, please unpack the parameter group.
3. Press FUNC/DATA key - to see the settings.
4. Press XX key to shift to the bit to be modified
5. Press ▲ or ▼ key - to change the setting
6, Press FUNC/DATA key - to save and auto-display next parameter (F006)
7, Press PRG key - to exit programming state
The application chart is as follows:
TD3200 Variable Speed Drive for Elevator Door Control User Manual
