Emerson Network Power TD3200 Series User Manual

Chapter 7 Application Guidance 87
Functions Name Setting Remark
F027 CD start torque 50.0%
F028 CD startup Acc time 1.0s
F029
Low speed in CD startup
process
8Hz
F030
Low-speed maintaining time
at CD startup
1.0s
F031
CD reference frequency
setting
30Hz
F032 CD Acc time 2.0s
F033
Initial time of "S" shape curve
in CD Acc process
20.0%
F034
Rising time of "S" shape
curve in CD Acc process
60.0%
F035 CD Dec time 2.0s
F036
Initial time of "S" shape curve
in CD Dec process
20.0%
F037
Dropping time of "S" shape
curve in CD Dec process
60.0%
F038
Low speed setting in CD
ending phase
2Hz
F039
Holding torque for complete
CD
50.0%
F040 Hindering torque for CD
100.0
%
F041
Threshold setting for CD
torque changing
50.0%
Parameters in the table are
factory settings, adjust the CD
parameters according to the
actual CD operating conditions.
F049
OD speed changing location
under distance control
70.0%
F050
CD speed changing location
under distance control
70.0%
F051
Pulse setting for complete OD
under distance control
90.0%
F052
Pulse setting for complete CD
under distance control
90.0%
Set according to actual operating
effects.
TD3200 Variable Speed Drive for Elevator Door Control User Manual
