38 Chapter 5 Parameters Table
Min.
Para. Name Range
unit
Default Mod.
F101 Function of X5
F102 Function of X6
F103 Function of X7
input
13: OD speed-shift contact normally
closed input
14: CD speed-shift contact normally open
input
15: CD speed-shift contact normally
closed input
16: MS terminal 1
17: MS terminal 2
18: MS speed terminal 3
19: OD prohibiting terminal input
20: Torque maitaining prohibiting terminal
input
21: Low speed OD/CD enabling input
22: Locking signal permanent ON input
23: Locking signal permenant OFF input
24: Operation enabling signal input (valid
only for X7)
1 0
×
F104
Function of
programmable
relay output
PA/PB/PC
4
×
F105
Function of
programmable
relay output
PAC/PC1
0
×
F106
Function of
programmable
relay output
PAC/PC2
0: Output signal 0 for completely OD
1: Output signal 0 for completely CD
2: Output signal 1 for completely OD
3: Output signal 1 for completely CD
4: Fault relay output 1(POFF state
excluded)
5: Fault relay output 2(POFF state
included)
6: Output signal 2 for completely OD
17: Output signal 2 for completely CD
8: Locking signal output
9: Door re-opening signal output
1
1
×
F107
Definition of
relay PC1 and
PC2 contacts
0~3 0 1
×
F108
OD priority
function setting
0
~
1
10
×
TD3200 Variable Speed Drive for Elevator Door Control User Manual
