40 Chapter 5 Parameters Table
Min.
Para. Name Range
unit
Default Mod.
F111
Parameters displayed
by LED in stopping
status
0: Preset OD frequency
(Hz)
1: Preset CD frequency
(Hz)
2: Status of digital input
terminal(no unit)
3: Status of digital output
terminal(no unit)
4: DC bus voltage (V-AVE)
5: MS frequency 0(Hz)
6: Low bit of pulse of door
location(0~9999)
7: High bit of pulse of door
location(0~9999)
1 0
○
F112 Type of 1st fault
F113 Type of 2nd fault
0: No abnormal
record(clear abnormal
record)
1: Acc over current (E001)
2: Dec over current (E002)
3: Constant speed over
current (E003)
4: Acc over voltage (E004)
5: Dec over voltage (E005)
6: Constant speed over
voltage (E006)
7~8: Reserved
9: Output side phase
loss(E009)
10: Reserved
11: Heatsink
overheat(E011)
12,14,15: Reserved
13: Drive overload
1 0
×
TD3200 Variable Speed Drive for Elevator Door Control User Manual
