Chapter 5 Parameters Table 41
Min.
Para. Name Range
unit
Default Mod.
F114 Type of 3rd fault
16: EEPROM R/W
fault(E016)
17~18: Reserved
19: Current detection
circuit fault(E019)
20: CPU fault
21~23: Reserved
24: Tuning fault(E024)
25~27: Reserved
28: Parameters setting
fault(E028)
29: Door-width
auto-learning fault(E029)
30: OD/CD operation
fault(E030)
1 0
×
F115
DC bus voltage (V) at
the latest fault
0~999V 1V 0V
×
F116
Output current (A) at
the latest fault
0.00~99.99A 0.01A 0.00A
×
F117
Output frequency at
the latest fault
0.00Hz~400.0Hz 0.01Hz 0.00Hz
×
F118
Status of input
terminal at the latest
fault
0~1023 (0: OFF; 1: ON)
CD/OD/X7/X6/X5/X4/X3/X
2/X1
1 0
×
F119
Status of output
terminal at the latest
fault
0~15 (0: OFF; 1: ON)
PR0/PR1/PR2
1 0
×
F120 Total operation time 0~65535 hour 1 0
×
F121
Temperature codes
used in factory
testing
0~9999 1 0
×
F122 Sofware version No. 32.XX - - -
