54 Chapter 6 Parameter Descriptions
F027 is used to set the start torque when the elevator door starts to close the
door so as to ensure good CD effects. The value of the torque is the product
by multiplying the setting of F027 by the rated torque.
F028 CD startup Acc time
Range: 0.1s~3600s
【
1.0
】
F028 is used to set the time taken for the elevator door to accelerate from
zero speed to low speed in CD startup process.
F029 Low speed in CD startup process
Range: 0~50.00Hz
【
8.00
】
F029 is used to set the target frequency (speed) of low operation speed in
CD process.
F030 Low-speed maintaining time at CD startup
Range: 0.1s~3600s
【
1.0
】
F030 is used to set the low-speed operating time including the Acc time and
constant speed operating time in CD startup process.
F031 CD reference frequency
Range: 0~Maximum frequency
【
30.00
】
F031 is used to set the high operating frequency (speed) in CD process.
F032 CD Acc time
Range: 0.1s~3600s
【
2.0
】
F032 is used to set the time taken for the drive to accelerate from the CD
startup low speed to the CD reference frequency in CD process.
F033 Initial time of S curve in CD Acc process
Range: 10.0%~50.0%
【
20.0%
】
F033 defines the ratio of the initial time of S curve (① of T1 in Figure 6-7 ) to
the whole Acc time T1. See Figure 6-7.
F034 Rising time of S curve in CD Acc process
Range: 10.0%~80.0%
【
60.0%
】
F034 defines the ratio of the rising time(② of T1 in Figure 6-7) of S curve to
the whole Acc time T1. See Figure 6-7.
F035 CD Dec time
Range: 0.1s~3600s
【
2.0
】
F035 defines time taken for the drive to decelerate from the CD reference
frequency (high speed) to the low speed in CD ending status.
F036 Initial time of S curve in CD Dec process
Range: 10.0%~50.0%
【
20.0%
】
F036 defines the ratio of the initial time(① of T2 in Figure 6-7) of S curve to
the whole Dec time, as shown in Figure 6-7.
TD3200 Variable Speed Drive for Elevator Door Control User Manual
