Emerson Affinity User Manual

Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Getting
Started
Basic
parameters
Running
the motor
Optimization
SMARTCARD
operation
PC tools
Advanced
parameters
Technical
Data
Diagnostics
UL Listing
Information
152 Affinity User Guide
www.controltechniques.com Issue Number: 5
Parameter
Range(
Ú) Default(Ö)
Type
OL RFC OL RFC
2.01 Post ramp reference ±SPEED_FREQ_MAX Hz/rpm
RO Bi NC PT
2.02 Ramp enable
OFF (0) or On (1) On (1) RW Bit US
2.03 Ramp hold OFF (0) or On (1) OFF (0) RW Bit US
2.04 Ramp mode select {0.14}
FASt (0)
Std (1)
Std.hV (2)
FASt (0)
Std (1)
Std (1) RW Txt US
2.06 S ramp enable OFF (0) or On (1) OFF (0) RW Bit US
2.07 S ramp acceleration limit
0.0 to 300.0
s
2
/100Hz
0.000 to 100.000
s
2
/1000rpm
3.1 1.500 RW Uni US
2.08 Standard ramp voltage 0 to DC_VOLTAGE_SET_MAX V
200V drive: 375
400V drive: EUR> 750
USA> 775
575V drive: 895
690V drive: 1075
RW Uni RA US
2.09 Deceleration failure detection OFF (0) or On (1) OFF (0) RW Bit US
2.10 Acceleration rate selector 0 to 9 0 RW Uni US
2.11 Acceleration rate 1 {0.03}
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
EUR> 40.0
USA> 33.3
EUR> 13.333
USA> 11.111
RW Uni US
2.12 Acceleration rate 2 RW Uni US
2.13 Acceleration rate 3 RW Uni US
2.14 Acceleration rate 4 RW Uni US
2.15 Acceleration rate 5 RW Uni US
2.16 Acceleration rate 6 RW Uni US
2.17 Acceleration rate 7 RW Uni US
2.18 Acceleration rate 8 RW Uni US
2.19 Jog acceleration rate 0.2 0.000 RW Uni US
2.20 Deceleration rate selector 0 to 9 0 RW Uni US
2.21 Deceleration rate 1 {0.04}
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
EUR> 40.0
USA> 33.3
EUR> 13.333
USA> 11.111
RW Uni US
2.22 Deceleration rate 2 RW Uni US
2.23 Deceleration rate 3 RW Uni US
2.24 Deceleration rate 4 RW Uni US
2.25 Deceleration rate 5 RW Uni US
2.26 Deceleration rate 6 RW Uni US
2.27 Deceleration rate 7 RW Uni US
2.28 Deceleration rate 8 RW Uni US
2.29 Jog deceleration rate 0.2 0.000 RW Uni US
2.32 Acceleration select bit 0
OFF (0) or On (1) OFF (0)
RW Bit NC
2.33 Acceleration select bit 1 RW Bit NC
2.34 Acceleration select bit 2 RW Bit NC
2.35
Deceleration select bit 0 RW Bit NC
2.36 Deceleration select bit 1 RW Bit NC
2.37 Deceleration select bit 2 RW Bit NC
2.38 Inertia compensation torque
± 1,000.0 % RO Bi NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
