Emerson Aventics G3 Series User Manual

G3 Series EtherCAT
TM
Technical Manual
2-11
TDG3ECM1-5EN 07/2020
Subject to change without notice
www.asco.com/g3
500 Series Z-Board™ Connectors
The 501, 502 and 503 valve series utilize 2 different Z-Board
™
designs to achieve the single and double solenoid
output functions. This yields the possible 32 single, 16 double, or various combinations of valve coil output
capabilities.
501 Series 502 Series
503 Series
