500 Series Extended Coil Capability
The Extended Coil manifolds must be connected to a G3 Electronics Node to operate. Not all G3 supported
protocols will support the Extended Coil Manifolds. Below is a list of the hardware and minimum firmware
levels that support the Extended Coil Manifolds.
Module firmware revision levels can be confirmed in the integrated graphic display and the built-in web
browser. See pg. 5-48 for more information.
Extended Coil Configuration
The Extended Coil Manifold can be configured to control 3 additional extended coil valve driver assemblies;
unless already configured from the factory. Modify the configuration with either the graphic display
interface as shown on page 5-34 or using the integrated web server configuration page shown on page 9-
85.
Extended Solenoid Coil Capability requirements:
Module
Part Number
Firmware
Communication Module
240-310
Rev 1.01 Build 42509
Valve Driver Module
P599AE508827001
Rev 4.019
Valve Series
Number of Extended
Coil Valve Drivers
Total number of coils
Configuration
Selection
Allocated number of I/O
Bytes designated for
valves
501
0 3-32 32 coils 4
1 33-64 64 coils 8
2 65-96 96 coils 12
3 97-128 128 coils 16
502/503
0 1-32 32 coils 4
1 33-48 64 coils 8
2 49-64 64 coils 8
3 65-80 96 coils 12
