Recommended External Fuses
External fuses should be chosen based upon the physical manifold configuration. Please refer to the
table below for the fuse sizing chart.
External Fuse Sizing Chart
Power Consumption - Power Connector Pin for Valves and Outputs
Description Current
Number of Solenoid Valve Coils Energized Simultaneously
___ X 0.167 A (ISO - SPA
Series)
= __________Amps
___ X 0.105 A (2012 and 2035
Series)
= __________Amps
___ X 0.056 A (2005
Series)
= __________Amps
___ X 0.021 A (2002
Series)
= __________Amps
Total load current drawn by simultaneously energized Discrete Outputs =
__________Amps
+
Number of I/O modules installed ___ X 0.023 A =
Valve Adapters (219-828) installed ___ X 0.134 A =
Communication Node Power Consumption =
Total: __________Amps
Surge Compensation: X 1.25
Suggested External +24 VDC (Valves and Outputs) Fuse Value:
Power Consumption – Power Connector Pin for Node and Inputs
Communication Node Power Consumption = .091 Amps
Total load current drawn by Sensor Devices from Discrete Inputs source =
__________Amps
+
Number of I/O modules installed ___ X 0.075 A = __________Amps
+
Total: __________Amps
Surge Compensation: X 1.25
Suggested External Pin +24 VDC (Node and Inputs) Fuse Value:
*Factory Default Settings
• The Node and Inputs Aux Power pins supply power to the node electronics. These pins
must be powered at all times for communication node and Inputs to be functional.
• The internal electronic fuses exist to protect against damage due to catastrophic failure
of internal components. External fuses are always recommended for protection against
power supply failure and over-current conditions.
