Emerson Aventics G3 Series User Manual

G3 Series EtherCAT
TM
Technical Manual
9-89
TDG3ECM1-5EN 07/2020
Subject to change without notice
www.asco.com/g3
501 Series, up to 64 solenoid coils
501 series, 4 station manifold block with an integrated 32 coil valve driver
• To be used with 501 series valves on valve manifold assemblies with 33-64 coils.
• Only to be used on assemblies where additional power, supply and/or exhaust capacity is not required
Byte X
Byte X+1
Byte X+2
Byte X+3
Byte X+4
Byte X+5
Byte X+6
Byte X+7
Integrated 32 coil valve driver
