Internal and external componentsFigure 2-1:
A. Gas calibration valve (valve 1)
B. Gas calibration valve (valve 2)
C. Gas inlet
D. Three-way valve
E. Three-way valve
F. Two-way valve
G. Gauge
H. Regulator
I. Filter
J. Slam shut valve
K. Flowmeter
L. Purge valve
M. SGM
N. Gas output two-way valve
O. Pressure relief one-way valve
