Options for Density Measurement UnitTable 8-1:
Unit description
Label
Display (standard) ProLink III Field Communicator
Grams per cubic centimeter
G/CM3 g/cm3 g/Cucm
Grams per liter
G/L g/l g/L
Grams per milliliter
G/mL g/ml g/mL
Kilograms per liter
KG/L kg/l kg/L
Kilograms per cubic meter
KG/M3 kg/m3 kg/Cum
Pounds per U.S. gallon
LB/GAL lbs/Usgal lb/gal
Pounds per cubic foot
LB/CUF lbs/ft3 lb/Cuft
Pounds per cubic inch
LB/CUI lbs/in3 lb/CuIn
Short ton per cubic yard
ST/CUY sT/yd3 STon/Cuyd
Degrees API
D API degAPI degAPI
Special unit
SPECL special Spcl
Define a special measurement unit for density
ProLink III
Device Tools > Configuration > Process Measurement > Line Density > Special Units
Field Communicator Configure > Manual Setup > Measurements > Optional Setup > Special Units
Overview
A special measurement unit is a user-defined unit of measure that allows you to report
process data in a unit that is not available in the transmitter. A special measurement unit is
calculated from an existing measurement unit using a conversion factor.
Procedure
1. Specify Density Special Unit Base.
Density Special Unit Base is the existing density unit that the special unit will be
based on.
2. Calculate Density Special Unit Conversion Factor as follows:
a. x base units = y special units
b. Density Special Unit Conversion Factor = x÷y
3. Enter Density Special Unit Conversion Factor.
The original density value is divided by this conversion factor.
4. Set User-Defined Label to the name you want to use for the density unit.
The special measurement unit is stored in the transmitter. You can configure the
transmitter to use the special measurement unit at any time.
