222 Powerdrive F300 User Guide
Issue Number: 2
11.13 Menu 12: Threshold detectors and variable selectors
Parameter
Range(
Ú) Default(Ö)
Type
OL RFC- A / S OL RFC-A RFC-S
12.001 Threshold Detector 1 Output Off (0) or On (1) RO Bit ND NC PT
12.002 Threshold Detector 2 Output Off (0) or On (1) RO Bit ND NC PT
12.003 Threshold Detector 1 Source 0.000 to 59.999 0.000 RW Num PT US
12.004 Threshold Detector 1 Level 0.00 to 100.00 %
0.00 %
RW Num US
12.005 Threshold Detector 1 Hysteresis 0.00 to 25.00 % RW Num US
12.006 Threshold Detector 1 Output Invert Off (0) or On (1) Off (0) RW Bit US
12.007 Threshold Detector 1 Destination
0.000 to 59.999 0.000
RW Num DE PT US
12.008 Variable Selector 1 Source 1 RW Num PT US
12.009 Variable Selector 1 Source 2 RW Num PT US
12.010 Variable Selector 1 Mode
Input 1 (0), Input 2 (1), Add (2), Subtract (3),
Multiply (4), Divide (5), Time Const (6), Ramp (7),
Modulus (8), Powers (9), Sectional (10)
Input 1 (0) RW Txt US
12.011 Variable Selector 1 Destination 0.000 to 59.999 0.000 RW Num DE PT US
12.012 Variable Selector 1 Output ±100.00 % RO Num ND NC PT
12.013 Variable Selector 1 Source 1 Scaling ±4.000 1.000 RW Num US
12.014 Variable Selector 1 Source 2 Scaling ±4.000 1.000 RW Num US
12.015 Variable Selector 1 Control 0.00 to 100.00 0.00 RW Num US
12.016 Variable Selector 1 Enable Off (0) or On (1) On (1) RW Bit US
12.023 Threshold Detector 2 Source 0.000 to 59.999 0.000 RW Num PT US
12.024 Threshold Detector 2 Level 0.00 to 100.00 %
0.00 %
RW Num US
12.025 Threshold Detector 2 Hysteresis 0.00 to 25.00 % RW Num US
12.026 Threshold Detector 2 Output Invert Off (0) or On (1) Off (0) RW Bit US
12.027 Threshold Detector 2 Destination 0.000 to 59.999 0.000 RW Num DE PT US
12.028 Variable Selector 2 Source 1 0.000 to 59.999 0.000 RW Num PT US
12.029 Variable Selector 2 Source 2 0.000 to 59.999 0.000 RW Num PT US
12.030 Variable Selector 2 Mode
Input 1 (0), Input 2 (1), Add (2), Subtract (3),
Multiply (4), Divide (5), Time Const (6), Ramp (7),
Modulus (8), Powers (9), Sectional (10)
Input 1 (0) RW Txt US
12.031 Variable Selector 2 Destination 0.000 to 59.999 0.000 RW Num DE PT US
12.032 Variable Selector 2 Output ±100.00 % RO Num ND NC PT
12.033 Variable Selector 2 Source 1 Scaling ±4.000 1.000 RW Num US
12.034 Variable Selector 2 Source 2 Scaling ±4.000 1.000 RW Num US
12.035 Variable Selector 2 Control 0.00 to 100.00 0.00 RW Num US
12.036 Variable Selector 2 Enable Off (0) or On (1) On (1) RW Bit US
RW Read / Write RO Read only Num Number parameter Bit Bit parameter Txt Text string Bin Binary parameter FI Filtered
ND No default value NC Not copied PT Protected parameter RA Rating dependent US User save PS Power-down save DE Destination
