CG Drives & Automation 01-7492-01r1 Functional description 115
Password [2726]
Password to login to router/AP when "[2721] WiFi Mode" =
Station or Password for clients to use if "[2721] WiFi Mode"
= AccessPoint. In case [2723] Encryption is WPA2
minimum password length is 8 characters. In case of WEP
only 5 or 13 character passwords are accepted.
If incorrect length of the password is entered, the PPU
displays "Invalid Pwd" message for two seconds and remains
in edit mode with last entered password.
Can't be read via field bus and not visible after entered.
IP Address [2727]
Shows static address to use if "[2724] DHCP" is set to
Static. Shows assigned address if "[2724] DHCP" is set to
DHCP. This is the IP address given to the Drive, use this
address in client software to connect to the AC Drive.
Subnet Mask [2728]
Shows static subnet mask to use if "[2724] DHCP" is set to
Static. Shows assigned subnet mask if "[2724] DHCP" is set
to DHCP.
Gateway [2729]
Shows assigned gateway if DHCP is selected in menu
“[2724] DHCP”.
WiFi Status [272A]
Status of WiFi module is shown in this menu "[272A] WiFi
Status". Status is set directly from control panel (that host
the WiFi module).
Bluetooth (BLE) options [273]
This menu is hidden if BLE not selected in menu “[271]
WirelessMode”.
BluetoothID [2731]
Shows bluetooth device ID if connected control panel have
bluetooth capability.
Paring key [2732]
Six digit numeric for the control panel BLE pairing with
mobile or other BLE device.
NOTE: The password should be entered left aligned.
2726 Password
Default 12345678
NOTE: Accepts only 32 - 126 ascii char in menus
SSID [2725] and Password [2726] entry as IEEE
standard speaks of 'printable ASCII characters' (in
the range of 32 to 126).
2727 IP Address
Default 192.168.1.1
2728 Subnet Mask
Default 255.255.255.0
2729 Gateway
Default 192.168.1.1
272A WiFi Status
Default OK
OK 0 No error
Mode error 1 Initialization failure of AP/Station mode
AP pwd err 2 AP password faulty
SSID error 3 SSID length error
SecPar error 4
Security parameters or SSID supplied is
wrong
Sta Disconn 5
Disconnect from router/AP in station
mode
NetConf err 6
Network configuration error (IP or
DHCP)
Config OK 7
If no error, this is shown 60 seconds
after configuration update, then it goes
back to OK.
2731 BluetoothID
Default 0
NOTE: Default is 0 or if a BLE control panel is used an
eight digit unique ID used in the broadcast name.
2732 Paring Key
Default 123456
