CG Drives & Automation 01-7492-01r1 171
Analogue Multiplexer 2 Operator [6223]
Operator of the Analogue Mux 2. The function is the same
as in Operator [6213].
11.6.3 Not Gate [630]
Output of the NOT gate is the inverted signal of the
selected input. NOT gates are used when some other
function (logic expression, digital out, virtual IO) needs the
inverted signal.
NOT1 Input [631]
NOT2 Input [632] - NOT8 Input [638]
Refer to the descriptions for NOT1 Input [631]. For default
values see chapter 15. page 227.
6223 AnMux2 Op
Default: Off
Selections: Same as in menu Operator
[6213].
631 NOT1 Input
Default: CA2
Selection: Same as in menu DigOut 1
[541].
