CG Drives & Automation 01-7492-01r1 189
11.9 System Data [900]
Main menu for viewing all the AC drive system data.
11.9.1 VSD Data [920]
VSD Type [921]
Shows the AC drive type according to the type number.
The options are indicated on the type plate of the AC drive.
Fig. 150 Example of AC drive type.
Examples
VFX48-046-5XAC drive-series
- suited for 380-480 volt mains supply, and a
- rated output current of 46 A.
- IP Class = IP54 and IP55 (2X = IP20/21)
Software [922]
Shows the software version number of the AC drive.
Fig. 151 gives an example of the version number.
Fig. 151 Example of software version
V 5.01= Software version
- 03.07 = option version, is only visible and valid for special
software, type OEM adapted software.
03 = (major) special software variant number
07= (minor) revision of this special software
Build Information [9221]
Software version created, date and time.
Build ID [9222]
Software identification code.
NOTE: If the control board is not configured, then
type shown is VFX48-###-##.
921
VFX2.1
VFX48-046-5X
Sby
922
Software
V 5.01 - 03.07
Sby
Table 42 Information for Modbus and Profibus number,
software version
Bit Example Description
7–0 32 Minor version
13–8 5 Major version
15–14
release
00: V, release version
01: P, pre-release version
10:
β, Beta version
11: α, Alpha version
Table 43 Information for Modbus and Profibus number,
option version
Bit Example Description
7–0 07 Minor option version
15–8 03 Major option version
NOTE: It is important that the software version
displayed in menu [922] is the same software version
number as the software version number written on
the title page of this instruction manual. If not, the
functionality as described in this manual may differ
from the functionality of the AC drive.
9221
Build Info
200616145041
Sby
Default:
YYMMDDHHMMSS
(YY=year, MM=month, DD=day,
HH=hours, MM=minutes, SS=seconds)
9222
Build ID
BEE5529E
Sby
