190 CG Drives & Automation 01-7492-01r1
EmoLib ID [9223]
Software library identification code.
Software configuration [9224]
Non-standard features are activated if the value is different
from zero.
Unit name [923]
Option to enter a name of the unit for service use or
customer identity. The function enables the user to define a
name with max 12 characters. Use the Prev and Next key to
move the cursor to the required position. Then use the +
and - keys to scroll in the character list. Confirm the
character by moving the cursor to the next position by
pressing the Next key. See section User-defined Unit [323].
Example
Create user name USER 15.
1. When in the menu [923] press Next to move the
cursor to the right most position.
2. Press the + key until the character U is displayed.
3. Press Next.
4. Then press the + key until S is displayed and con-
firm with Next.
5. Repeat until you have entered USER15.
When sending a unit name you send one character at a time
starting at the right most position.
Hardware [924]
CB Key [9241]
Unique identifier of control board; 32 bit hex value.
CtrlPanel [925]
This menu and sub menus will be hidden if an older control
panel is connected.
Control panel software version [9251]
Shows the software version number of the control panel.
Fig. 151 gives an example of the version number.
Fig. 152 Example of software version
V 2.00 = Software version
CP HW ver [9252]
Hardware version of connected control panel.
CP Build ID [9253]
32 bit hex value of build ID for control panel.
Fig. 153 gives an example of the version number.
Fig. 153 Example of control panel build ID.
9223
EmoLib ID
9A12D134
Sby
9224
SW Config
0
Sby
Default 0
923
Unit Name
Sby
Default: 0
9241
CB Key
00DBDA8B
Sby
Example: 00DBDA8B
9251
CP SW ver
V 2.00
Sby
9252
CP HW ver
11
Sby
9253
CP Build ID
64A26CE5
Sby
