150 CG Drives & Automation 01-7492-01r1
11.4.3 Trip text [430]
ExtTrip1 Text [431]
Used for custom external trip messages of maximum 16
characters. Editing of the message text is done according to
the same principles as described for the Unit name [923].
ExtTrip2 Text [432]
Used for custom external trip messages of maximum 16
characters. Editing of the message text is done according to
the same principles as described for the Unit name [923].
ExtTrip3 Text [433]
Used for custom external trip messages of maximum 16
characters. Editing of the message text is done according to
the same principles as described for the Unit name [923].
ExtTrip4 Text [434]
Used for custom external trip messages of maximum 16
characters. Editing of the message text is done according to
the same principles as described for the Unit name [923].
11.5 I/Os and Virtual
Connections [500]
Main menu with all the settings of the standard inputs and
outputs of the AC drive.
11.5.1 Analogue Inputs [510]
Submenu with all settings for the analogue inputs.
AnIn1 Function [511]
Sets the function for Analogue input 1. Scale and range are
defined by AnIn1 Advanced settings [513].
Adding analogue inputs
If more than one analogue input is set to the same function,
the values of the inputs can be added together. In the
following examples we assume that Process Source [321] is
set to Speed.
Example 1: Add signals with different weight (fine tuning).
Signal on AnIn1 = 10 mA
Signal on AnIn2 = 5 mA
[511] AnIn1 Function = Process Ref.
[512] AnIn1 Setup = 4-20 mA
[5134] AnIn1 Function Min = Min (0 rpm)
[5136] AnIn1 Function Max = Max (1500 rpm)
[5138] AnIn1 Operation = Add+
[514] AnIn2 Function = Process Ref.
[515] AnIn2 Setup = 4-20 mA
[5164] AnIn2 Function Min = Min (0 rpm)
[5166] AnIn2 Function Max = User defined
[5167] AnIn2 Value Max = 300 rpm
[5168] AnIn2 Operation = Add+
431 ExtTrip1Text
Default: Ext Trip 1
432 ExtTrip2Text
Default: Ext Trip 2
433 ExtTrip3Text
Default: Ext Trip 3
434 ExtTrip4Text
Default: Ext Trip 4
511 AnIn1 Fc
Default: Process Ref
Off 0 Input is not active
Max Speed 1 The input acts as an upper speed limit.
Max Torque 2 The input acts as an upper torque limit.
Process
Val
3
The input value equals the actual process
value (feedback) and is compared to the
reference signal (set point) by the PID
controller, or can be used to display and
view the actual process value.
Process
Ref
4
Reference value is set for control in
process units, see Process Source [321]
and Process Unit [322].
Min Speed 5 The input acts as a lower speed limit.
NOTE: When AnInX Func=Off, the connected signal
will still be available for Comparators [610].
